KNUTH "Servomill 700" SERVOCONVENTIONAL MILLING MACHINE - $RFQ

Item Number: #00154382
KNUTH &quot;Servomill 700&quot; SERVOCONVENTIONAL MILLING MACHINE

KNUTH "Servomill 700" SERVOCONVENTIONAL MILLING MACHINE
Stock Code:  16178
Price: $RFQ
Subcategory:

Miscellaneous Machinery

Manufacturer:  Knuth
Model:  SERVOMILL 700
Condition: New

<p></p><div class="additional-attributes-wrapper table-wrapper table-responsive">

<table class="data table additional-attributes"><caption class="table-caption">Working Area</caption><tbody><tr class="mer_aaachb"><td>Table set up area</td><td>54x12 in</td></tr><tr class="mer_aaachc"><td>Table load capacity (max.)</td><td>770 lbs</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Travels</caption><tbody><tr class="mer_aaacih"><td>Travel X-axis</td><td>26.8 in</td></tr><tr class="mer_aaacii"><td>Travel Y-axis</td><td>14 in</td></tr><tr class="mer_aaacij"><td>Travel Z-axis</td><td>15 in</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Vertical Milling Head</caption><tbody><tr class="mer_aaaigb"><td>Speed range (infinitely variable, back gear ranges)</td><td>50 - 4,000 rpm</td></tr><tr class="mer_aaajec"><td>Spindle mount</td><td>ISO 40 </td></tr><tr class="mer_aaajca"><td>Quill stroke</td><td>5 in</td></tr><tr class="mer_aaajdg"><td>Spindle nose-to-table surface distance</td><td>7 - 22 in</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Rapid Feed</caption><tbody><tr class="mer_aaaaid"><td>Rapid Feed X-axis</td><td>196.85 in/min</td></tr><tr class="mer_aaaaie"><td>Rapid Feed Y-axis</td><td>118.11 in/min</td></tr><tr class="mer_aaaaif"><td>Rapid Feed Z-axis</td><td>78.74 in/min</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Feed</caption><tbody><tr class="mer_aaaifj"><td>Feed speed (infinitely variable)</td><td>0 - 39 in/min</td></tr><tr class="mer_aaaiga"><td>Feed per spindle revolution</td><td>0 - 0.04 in/R</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Drive Capacity</caption><tbody><tr class="mer_aaabfj"><td>Motor rating main drive</td><td>5 Hp</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Measures and Weights</caption><tbody><tr class="mer_aaaaac"><td>Overall dimensions (length x width x height)</td><td>100x86x89 in</td></tr><tr class="mer_aaabai"><td>Weight</td><td>3,960 lbs</td></tr></tbody></table> <table class="data table additional-attributes" id="product-attribute-specs-table">
<tbody>
<tr>
<td class="col" scope="row">Part No.</td>
<td class="col data" data-th="Part No.">301250</td>
</tr>
</tbody>
</table>
</div><p></p><p>
</p><div class="col-xs-12 product attribute description">
<div class="value">
<p style="font-weight: bold;">Conventional milling, now easier, more precise and more efficient due to integrated electronics</p><ul><li>The Servomill represents a new generation of advanced milling machines that are operated like a conventional machine</li><li>This machine features a user-friendly design, significantly higher precision and increased machining capacity</li><li>Very high reliability and long service life of all components ensure drastically reduced maintenance and increased reliability</li><li>Rigid machine base in a proven design, and meticulous workmanship</li><li>Variability via swiveling and moving top beam</li><li>Perfectly adjustable dovetail guide on the X axis, and wide square guides in Y and Z direction</li><li>High-precision preloaded ball screws on all 3 axes</li><li>All guides are hardened and ground, and are supplied with oil by the central lubrication unit</li><li>Cutter head swivels with pneumatic tool clamping and powerful 5 HP motor</li><li>Infinitely variable spindle speed with back gearing and LED speed indicator</li><li>Manual quill feed with micrometer depth stop allows for precise angular bores</li><li>Large, swiveling control panel with integrated position indicator</li></ul><p style="font-weight: bold;">Servomill - Highlights</p><ul><li>Control developed and built in Germany</li><li>Positioning control for traveling pre-selected paths on all axes</li><li>Constant cutting speed, where the feed speed is based on spindle speed</li><li>Zero-backlash preloaded ball screws</li><li>Servo motors on all axes, infinitely variable feed, rapid feed, and speed control</li><li>Electronic spindle load indicator</li><li>Electronic hand-wheels on all axes</li><li>X, Y and Z axes can be controlled via joystick</li><li>Integrated position indicator with glass scale</li></ul><p style="font-weight: bold;">Your Advantages:</p><ul><li>Easy to use: intuitive operation - practical layout of control elements and streamlined function</li><li>Automatic feed on all axes and infinitely variable rapid feed</li><li>With speeds up to 197 in/min</li><li>Set limit stops on any axis with the push of a button - 3 stop positions per axis can be stored</li><li>More precise: operated via electronic hand-wheels - axes are powered by high-quality servo drives that translate your hand movements with the precision and dynamics of modern CNC machines</li><li>More reliable: drives, spindles, and measuring systems are totally enclosed or mounted in protective enclosures and virtually maintenance-free</li><li>Electronics - made in Germany</li><li>More capacity: this machine only uses premium drive components that are designed for continuous operation</li><li>Maintenance-free: no regular maintenance needed for the entire feed drive</li></ul><ul><li>Advanced Feed Technology:</li><li>Axes are powered by high-quality servo drives that translate your hand movements with the precision and dynamics of modern CNC machines</li><li>Reliable, maintenance-free mass production technology</li><li>High rapid feed rate for reduced machine down-times</li><li>Ball screw drive on all axes:</li><li>Considerably less errors due to loseness (backlash), resulting in significantly higher precision</li><li>Significantly reduced friction, no stick-slip effect, reduced heat buildup, minimal wear</li><li>Electronic hand-wheels:</li><li>Micro-control via electronic hand-wheels offering the same handling and postioning as with a conventional machine, just smoother and more precise</li><li>Joystick control:</li><li>Maximum operator comfort for axis movements</li><li>Easy handling during sequential processing</li><li>Electronically controlled fixed stops:</li><li>Set 2 limit stops at 3 positions on each axis by the push of a button - these buttons are grouped around the feed switch for intuitive control</li><li>This ensures high repeatability during coordinate drilling or pocket cutting, and siginificantly more positions can be set up than on conventional machines</li><li>Constant cutting speed:</li><li>The feed rate is infinitely variable and can be coupled with the spindle speed in a selectable feed-per-spindle revolution ratio in the range of 0.0004 to 0.04 inch/rev</li><li>This ensures a constant feed-per-tooth value and simplifies the operator's task of optimizing the machining operation</li><li>Electronic spindle load indicator:</li><li>Assists the operator in the most efficient utilization of machine and tool capacities</li><li>Reliable indicator helps avoid damages caused by overloads</li></ul><p style="font-weight: bold;">X.pos Plus - You will gain productivity,
quality and comfort</p><ul><li>Default coordinates</li><li>Hole circle pattern calculation</li><li>Vibration filter feature</li><li>Mm/inch conversion</li><li>8 display languages</li><li>Calculator function</li><li>high-resolution display with excellent legibility</li><li>state-of-the art electronics and a very robust, completely sealed enclosure ensure maximum safety and optimum production conditions</li><li>a major focus during the development and selection of electronic components was the achievement of maximum resistance against external interferences and maintaining low temperature levels</li><li>background colors of the display can be changed as required or desired</li><li>the keyboard membrane is highly resistant and yet very comfortable to touch</li><li>the display also provides a key to toggle between radius and diameter</li><li>the axis position is maintained when the display is turned off</li><
