<p></p><div class="additional-attributes-wrapper table-wrapper table-responsive">

<table class="data table additional-attributes"><caption class="table-caption">Working Area</caption><tbody><tr class="mer_aaaebb"><td>Center height</td><td>7 in</td></tr><tr class="mer_aabaai"><td>Workpiece length (max.)</td><td>39 in</td></tr><tr class="mer_aababc"><td>Grinding length</td><td>39 in</td></tr><tr class="mer_aaadbb"><td>Work piece weight (max.)</td><td>330 lbs</td></tr><tr class="mer_aaafed"><td>Grinding diameter</td><td>12.6 in</td></tr><tr class="mer_aaabdd"><td>Inside grinding diameter</td><td>1.2 - 3.9 in</td></tr><tr class="mer_aaabdf"><td>Inside grinding depth</td><td>4.9 in</td></tr><tr class="mer_aaajjb"><td>Table swivel range (max.)</td><td>7¡ / 3¡ R / L</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Travels</caption><tbody><tr class="mer_aaacih"><td>Travel X-axis</td><td>7.9 in</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Feed</caption><tbody><tr class="mer_aaaeii"><td>Table feed, infinitely variable</td><td>0.33 - 13.08 fpm</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Headstock</caption><tbody><tr class="mer_aaaahc"><td>Working spindle speed, infinitely variable</td><td>25 - 220 rpm</td></tr><tr class="mer_aaagej"><td>Work piece headstock swivel range r/l</td><td>360¡ / 90¡ pitch </td></tr><tr class="mer_aaafee"><td>Working spindle taper</td><td>MT 4</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Grinding headstock</caption><tbody><tr class="mer_aaaahe"><td>Grinding spindle speed</td><td>1,670 rpm</td></tr><tr class="mer_aaaahd"><td>Inside grinding spindle speed</td><td>10,000 rpm</td></tr><tr class="mer_aaacdh"><td>Grinding headstock swivel range (r+l)</td><td>30¡ / 180¡ </td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Tailstock</caption><tbody><tr class="mer_aaabje"><td>Tailstock taper</td><td>MT 4</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Drive Capacity</caption><tbody><tr class="mer_aaafff"><td>Motor rating working spindle</td><td>2 Hp</td></tr><tr class="mer_aaaejc"><td>Motor rating outside grinding</td><td>7.4 Hp</td></tr><tr class="mer_aaaejb"><td>Motor rating inside grinding</td><td>1.5 Hp</td></tr><tr class="mer_aaahaf"><td>Motor rating X axis feed</td><td>2.4 Hp</td></tr><tr class="mer_aaahag"><td>Motor rating Z axis feed</td><td>3.9 Hp</td></tr></tbody></table><table class="data table additional-attributes"><caption class="table-caption">Measures and Weights</caption><tbody><tr class="mer_aaacbb"><td>Grinding wheels dimensions</td><td>16x2x8 in</td></tr><tr class="mer_aaaaac"><td>Overall dimensions (length x width x height)</td><td>166x89x71 in</td></tr><tr class="mer_aaabai"><td>Weight</td><td>11,660 lbs</td></tr></tbody></table> <table class="data table additional-attributes" id="product-attribute-specs-table">
<tbody>
<tr>
<td class="col" scope="row">Part No.</td>
<td class="col data" data-th="Part No.">101145</td>
</tr>
</tbody>
</table>
</div><p></p><p>
</p><div class="col-xs-12 product attribute description">
<div class="value">
<ul><li>Superior machining quality and high flexibility for small batch productions</li><li>These proven, solid machine frames with wide V-guides and boxways ensure low vibrations for optimum work results</li><li>Servo-driven axes run on precision preloaded ball screws</li><li>Electronic hand-wheels for grinding headstock movement</li><li>High-precision hydrodynamic bearings of the grinding spindle ensure optimum grinding results</li><li>Fagor control, optimized for grinding cycles</li></ul> </div>
</div>
<p></p><p></p><div class="col-xs-12 product attribute steuerung_description">
<div class="value">
<p style="font-weight: bold;">Innovative, intuitive and customized</p><ul><li>Featuring standard cycles plus KNUTH-specific cycle user interface that can be customized to match the existing machine configuration - for maximual utilization and optimized processes</li><li>The workpiece can be programmed via cycles or G-codes (DIN ISO) or a combination of both systems</li><li>grinding wheel can be dressed prior or during the entire machining process (incl. compensation)</li><li>automatic grinding wheel dressing cycle can be selected before finishing operation (incl. compensation)</li><li>manual swing grinding mode, like on a conventional machine, but with electronic hand-wheels</li><li>USB port at front of control, configuration with RS 232 &amp; Ethernet (optional) data ports is possible (incl. date transfer software)</li><li>cycle Examples: Plunge-cut grinding, plunge-cut grinding with oscillation, and cylindrical grinding</li></ul> </div>
</div>
<p></p><p></p><div class="col-xs-12 product attribute standardequipment">
<div class="value">
<ul class="supplies"><li>control Fagor 8055i FL-TCO</li><li>internal grinding equipment</li><li>3-jaw chuck</li><li>steady rest</li><li>follow rest</li><li>grinding wheel balancing station</li><li>balancing mandrel</li><li>center MT 4</li><li>inside grinding arbor</li><li>foundation bolts</li><li>coolant System with magnetic separator</li><li>automatic central lubrication</li><li>leveling feet</li><li>work lamp</li><li>operating tools</li><li>operating manual and programming instructions</li></ul> </div>
</div>
<p></p>

This machine is listed for sale by Blumberg Machinery located in Bannockburn, Illinois
