Swing Over Cross Slide
13.5"
Distance Between Centers
40"
Spindle Nose Mounting
STD: D1-8
Taper of Spindle Bore
MT #7 (Sleeve MT #5)
Range Of Spindle Speeds
Auto Shift High - Middle - Low
Longitudinal Travel (Z Axis)
34.5"
Cross Slide Travel (X Axis)
11.6"
Rapid Travel/Cutting Feed Rate
270/120 ipm
Max. Size Cutting Tool
1 " (4 Way Tool Post)
Coolant Tank Capacity
6 Gallons
Warranty
One Year Limited Warranty
Voltage
208V to 230V (Max) ~ 3 Phase
Dimensions (L x W x H)
96" x 74" x 77"
Centroid T400i Control With 15" Color LCD
10 H.P. Spindle Motor, D1-8, 3-3/8" Through Hole Spindle
Max. 2000 Rpm Spindle Speed With Auto Shift 3 Gear Range
C5 Double Nut Precision Ball Screws Hardened & Ground For High Accuracy & Long Lasting
FC30 Mechanite Casting Main Frame With Annealed & Stressed Relieved For Long Term Reliability
Hardened & Ground With Turcite-B Coating Guide Way
Massive One Piece Casting Construction For Maximum Cutting Performance
Central Lubrication System
14" Wide Bed Ways Designed To Provide Maximum Rigidity & Stability
100% Laser Tested For Positioning Accuracy & Repeatability
Dual Hand Wheel For Manual Operation
60 GB Solid State Hard Drive
Built-In Quartz Work Light
Shop Floor Programming/Conversational
